Mechanism of Schisandrae Chinensis Fructus on Treating Missed Abortion Based on Network Pharmacology and Preliminary Verification

doi:10.12280/gjfckx.20230445

Abstract

Abstract:

Objective: To explore the potential mechanism of Schisandrae chinensis fructus on the treatment of missed abortion based on a network pharmacology approach and verified experimentally. Methods: The system pharmacology approach was used to find and screen the active components and targets of Schisandrae chinensis from the Traditional Chinese Medicine Systems Pharmacology Database and Analysis Platform (TCMSP, https://old.tcmsp-e.com/tcmsp.php), find the genes related to missed abortion, and identify the targets of Schisandra chinensis for prevention and treatment of missed abortion. The "drug component-target" network was constructed by using Cytoscape to screen key compounds. The protein-protein interaction (PPI) network was established by String, and the core targets were screened by the Cytoscape-CytoNCA topology analysis. Gene ontology (GO) and kyoto encyclopedia of genes and genomes (KEGG) analysis were performed on the target genes to predict their possible signal pathways and explore their molecular mechanisms. Finally, the mechanism was validated with the help of human chorionic villous trophoblast cell line (HTR-8/SVneo) using real-time fluorescence quantitative polymerase chain reaction (qRT-PCR) detection and Western blotting assays. Results: Seven active compounds of Schisandra chinensis were identified from TCMSP database. Schisandrae chinensis has five potential targets for the prevention and treatment of missed abortion. The PPI network shows that androgen receptor (AR), estrogen receptor (ER), cyclooxygenase-2 (COX-2), nuclear receptor coactivator 2 (NCOA2) and acetylcholine esterase (ACHE) may be the core targets of Schisandrae chinensis for the prevention and treatment of missed abortion. Forty-four cell biological processes were obtained by GO enrichment analysis, and two related signal pathways were obtained by KEGG pathway enrichment analysis, mainly including thyroid hormone signal pathway and estrogen signal pathway. During the process of validating the mechanism using a cell model, it was found that the protein and/or mRNA levels of AR, ER, and COX-2 in cells treated with benzo(a)pyren-7, 8-dihydrodiol-9, 10-epoxide (BPDE) were higher than those of normal cells, while the protein and/or mRNA levels of AR, ER, and COX-2 were reduced in cells pretreated with Schisandrin B (Sch B) first and then tainted with BPDE compared with those not pretreated with Sch B. The NCOA2 and ACHE protein and/or mRNA levels did not change significantly. Conclusions: Schisandrae chinensis may exert its preventive and therapeutic effects on missed abortion through anti-inflammatory and hormonal receptor regulation, and this protective effect may be achieved through the estrogen signaling pathway.

Key words: Schisandrae chinensis fructus, Abortion, missed, Mechanism, Network pharmacology

LIANG Jing, QIAO Lin-jing, HOU Hai-yan. Mechanism of Schisandrae Chinensis Fructus on Treating Missed Abortion Based on Network Pharmacology and Preliminary Verification[J]. Journal of International Obstetrics and Gynecology, 2024, 51(2): 167-175.

Figures/Tables 8

References 35

[1]	郑峥, 顾向应, 刘欣燕, 等. 早期妊娠稽留流产治疗专家共识[J]. 中国实用妇科与产科杂志, 2020, 36(1):703. doi: 10.19538/j.fk2020010117.
[2]	Chen BA, Creinin MD. Contemporary management of early pregnancy failure[J]. Clin Obstet Gynecol, 2007, 50(1):67-88. doi: 10.1097/GRF.0b013e31802f1233. pmid: 17304025
[3]	Fang J, Xie B, Chen B, et al. Biochemical clinical factors associated with missed abortion independent of maternal age: A retrospective study of 795 cases with missed abortion and 694 cases with normal pregnancy[J]. Medicine(Baltimore), 2018, 97(50):e13573. doi: 10.1097/MD.0000000000013573.
[4]	梁婧, 侯海燕, 孙旸, 等. 五味子提取物对苯并[a]芘暴露致妊娠早期大鼠胚胎损伤的保护作用[J]. 中国中西医结合杂志, 2016, 36(2):234-238.
[5]	梁婧, 王华, 侯海燕, 等. 五味子提取物对苯并[a]芘诱导的早孕期大鼠胚胎损伤的保护作用及凋亡机制研究[J]. 中国药理学通报, 2015, 31(3):381-387. doi: 10.3969/j.issn.1001-1978.2015.03.017.
[6]	梁婧, 侯海燕, 王梦, 等. 苯并芘的早期妊娠毒性及五味子提取物在胚胎损伤中的保护作用[J]. 国际生殖健康/计划生育杂志, 2019, 38(1):10-15. doi: 10.3969/j.issn.1674-1889.2019.01.002.
[7]	国家药典委员会. 中华人民共和国药典:一部[M]. 北京: 中国医药科技出版社, 2020:68.
[8]	胡召娣, 杨艳芳, 李兰兰, 等. 五味子治疗男性不育症作用机制研究进展[J]. 辽宁中医药大学学报, 2023, 25(6):60-64. doi:10.13194/j.issn.1673-842x.2023.06.012.
[9]	Karna KK, Choi BR, Kim MJ, et al. The Effect of Schisandra chinensis Baillon on Cross-Talk between Oxidative Stress, Endoplasmic Reticulum Stress, and Mitochondrial Signaling Pathway in Testes of Varicocele-Induced SD Rat[J]. Int J Mol Sci, 2019, 20(22):5785. doi: 10.3390/ijms20225785.
[10]	Hong SH, Li M, Jeung EB, et al. Therapeutic effects of Schisandra chinensis on the hyperprolactinemia in rat[J]. Int J Oncol, 2017, 50(4):1448-1454. doi: 10.3892/ijo.2017.3881.
[11]	Li ZC, Huang MH, Zhong WQ, et al. Identification of drug-target interaction from interactome network with ′guilt-by-association′ principle and topology features[J]. Bioinformatics, 2016, 32(7):1057-1064. doi: 10.1093/bioinformatics/btv695.
[12]	梁婧, 侯海燕, 王梦, 等. 苯并芘代谢产物BPDE的细胞毒性研究及五味子乙素在预防HTR-8/SVneo细胞损伤中的作用[J]. 国际生殖健康/计划生育杂志, 2020, 39(1):5-11. doi:10.3969/j.issn.1674-1889.2020.01.001.
[13]	Sobinoff AP, Pye V, Nixon B, et al. Jumping the gun: smoking constituent BaP causes premature primordial follicle activation and impairs oocyte fusibility through oxidative stress[J]. Toxicol Appl Pharmacol, 2012, 260(1):70-80. doi: 10.1016/j.taap.2012.01.028.
[14]	Bolton JL, Trush MA, Penning TM, et al. Role of quinones in toxicology[J]. Chem Res Toxicol, 2000, 13(3):135-160. doi: 10.1021/tx9902082. pmid: 10725110
[15]	Penning TM, Burczynski ME, Hung CF, et al. Dihydrodiol dehydrogenases and polycyclic aromatic hydrocarbon activation: generation of reactive and redox active o-quinones[J]. Chem Res Toxicol, 1999, 12(1):1-18. doi: 10.1021/tx980143n. pmid: 9894013
[16]	Kim HS, Kwack SJ, Lee BM. Lipid peroxidation, antioxidant enzymes, and benzo[a]pyrene-quinones in the blood of rats treated with benzo[a]pyrene[J]. Chem Biol Interact, 2000, 127(2):139-150. doi: 10.1016/s0009-2797(00)00177-0.
[17]	Poston L, Raijmakers MT. Trophoblast oxidative stress, antioxidants and pregnancy outcome--a review[J]. Placenta, 2004, 25(Suppl A):S72-S78. doi: 10.1016/j.placenta.2004.01.003.
[18]	Huang X, Xi Y, Pan Q, et al. Caffeic acid protects against IL-1β-induced inflammatory responses and cartilage degradation in articular chondrocytes[J]. Biomed Pharmacother, 2018, 107:433-439. doi: 10.1016/j.biopha.2018.07.161. pmid: 30103115
[19]	Leimert KB, Messer A, Gray T, et al. Maternal and fetal intrauterine tissue crosstalk promotes proinflammatory amplification and uterine transition[J]. Biol Reprod, 2019, 100(3):783-797. doi: 10.1093/biolre/ioy232.
[20]	Busch F, Mobasheri A, Shayan P, et al. Resveratrol modulates interleukin-1β-induced phosphatidylinositol 3-kinase and nuclear factor κB signaling pathways in human tenocytes[J]. J Biol Chem, 2012, 287(45):38050-38063. doi: 10.1074/jbc.M112.377028. pmid: 22936809
[21]	Lunnon K, Keohane A, Pidsley R, et al. Mitochondrial genes are altered in blood early in Alzheimer′s disease[J]. Neurobiol Aging, 2017, 53:36-47. doi: 10.1016/j.neurobiolaging.2016.12.029. pmid: 28208064
[22]	Weng MW, Hsiao YM, Chen CJ, et al. Benzo[a]pyrene diol epoxide up-regulates COX-2 expression through NF-kappaB in rat astrocytes[J]. Toxicol Lett, 2004, 151(2):345-355. doi: 10.1016/j.toxlet.2004.03.007.
[23]	Guo L, Wei M, Li B, et al. The Role of Cyclooxygenases-2 in Benzo(a)pyrene-Induced Neurotoxicity of Cortical Neurons[J]. Chem Res Toxicol, 2020, 33(6):1364-1373. doi: 10.1021/acs.chemrestox.9b00451.
[24]	Wang F, Hu S, Ma DQ, et al. ER/AR Multi-Conformational Docking Server: A Tool for Discovering and Studying Estrogen and Androgen Receptor Modulators[J]. Front Pharmacol, 2022, 13:800885. doi: 10.3389/fphar.2022.800885.
[25]	Rice C, Birnbaum LS, Cogliano J, et al. Exposure assessment for endocrine disruptors: some considerations in the design of studies[J]. Environ Health Perspect, 2003, 111(13):1683-1690. doi: 10.1289/ehp.5798.
[26]	Colborn T, vom Saal FS, Soto AM. Developmental effects of endocrine-disrupting chemicals in wildlife and humans[J]. Environ Health Perspect, 1993, 101(5):378-384. doi: 10.1289/ehp.93101378.
[27]	Arnold SF, Collins BM, Robinson MK, et al. Differential interaction of natural and synthetic estrogens with extracellular binding proteins in a yeast estrogen screen[J]. Steroids, 1996, 61(11):642-646. doi: 10.1016/s0039-128x(96)00183-3. pmid: 8916358
[28]	Gray LE Jr, Ostby J, Cooper RL, et al. The estrogenic and antiandrogenic pesticide methoxychlor alters the reproductive tract and behavior without affecting pituitary size or LH and prolactin secretion in male rats[J]. Toxicol Ind Health, 1999, 15(1/2):37-47. doi: 10.1177/074823379901500105.
[29]	Masih J, Masih A, Kulshrestha A, et al. Characteristics of polycyclic aromatic hydrocarbons in indoor and outdoor atmosphere in the North central part of India[J]. J Hazard Mater, 2010, 177(1/2/3):190-198. doi: 10.1016/j.jhazmat.2009.12.017.
[30]	Wang L, Hu W, Xia Y, et al. Associations between urinary polycyclic aromatic hydrocarbon metabolites and serum testosterone in U.S. adult males: National Health and nutrition examination survey 2011-2012[J]. Environ Sci Pollut Res Int, 2017, 24(8):7607-7616. doi: 10.1007/s11356-017-8407-9.
[31]	Mise H, Yura S, Itoh H, et al. The relationship between maternal plasma leptin levels and fetal growth restriction[J]. Endocr J, 2007, 54(6):945-951. doi: 10.1507/endocrj.k06-225. pmid: 18000344
[32]	Fishman H, Madiwale S, Geron I, et al. ETV6-NCOA2 fusion induces T/myeloid mixed-phenotype leukemia through transformation of nonthymic hematopoietic progenitor cells[J]. Blood, 2022, 139(3):399-412. doi: 10.1182/blood.2020010405.
[33]	Qu L, Yin Y, Yin T, et al. NCOA2-induced secretion of leptin leads to fetal growth restriction via the NF-κB signaling pathway[J]. Ann Transl Med, 2023, 11(4):166. doi:10.21037/atm-22-6444. pmid: 36923094
[34]	Vieira LR, Gravato C, Soares AM, et al. Acute effects of copper and mercury on the estuarine fish Pomatoschistus microps: linking biomarkers to behaviour. Chemosphere[J]. 2009, 76(10):1416-1427. doi:10.1016/j.chemosphere.2009.06.005.
[35]	Zhen H, Wen M, Yang Y, et al. Toxic effects of HgCl₂ on activities of SOD, AchE and relative expression of SOD, AChE, CYP1A1 of zebrafish[J]. Ecotoxicology, 2014, 23(10):1842-1845. doi:10.1007/s10646-014-1350-3. pmid: 25240424

基因名称	上游引物（5′~3′）	下游引物（5′~3′）	片段长度（bp）
COX-2	AGAGCAGAGAGATGAAATACC	AGGAGAACAGATGGGATTAC	266
AR	CTACATCAAGGAACTCGATCGT	CATGTGTGACTTGATTAGCAGG	159
ER	TACTGCATCAGATCCAAGGGAA	CCTCGGGGTAGTTGTACAC	128
NCOA2	GCTGCACAAACGAAGAGCAA	CATGTCCTGACCTGGGTTCC	210
ACHE	AGCGACTGATGCGATACTGG	CCATGGGTGAAGCCTGGG	250
GAPDH	CAGGAGGCATTGCTGATGAT	GAAGGCTGGGGCTCATTT	137

基因名称	上游引物（5′~3′）	下游引物（5′~3′）	片段长度（bp）
COX-2	AGAGCAGAGAGATGAAATACC	AGGAGAACAGATGGGATTAC	266
AR	CTACATCAAGGAACTCGATCGT	CATGTGTGACTTGATTAGCAGG	159
ER	TACTGCATCAGATCCAAGGGAA	CCTCGGGGTAGTTGTACAC	128
NCOA2	GCTGCACAAACGAAGAGCAA	CATGTCCTGACCTGGGTTCC	210
ACHE	AGCGACTGATGCGATACTGG	CCATGGGTGAAGCCTGGG	250
GAPDH	CAGGAGGCATTGCTGATGAT	GAAGGCTGGGGCTCATTT	137

成分代码	化合物名称	口服生物利用度（%）	药物相似性	靶点	靶点通用名
MOL004624	Longikaurin A	47.72	0.53	Muscarinic acetylcholine receptor M1	CHRM1
				Muscarinic acetylcholine receptor M2	CHRM2
				Trypsin-1	PRSS1
MOL005317	Deoxyharringtonine	39.27	0.81	Androgen receptor	AR
				Mineralocorticoid receptor	NR3C2
MOL008956	Angeloylgomisin O	31.97	0.85	Androgen receptor	AR
MOL008957	Schizandrer B	30.71	0.83	Prostaglandin G/H synthase 2	PTGS2*
MOL008968	Gomisin A	30.69	0.78	Acetylcholinesterase	ACHE
MOL008978	Gomisin R	34.84	0.86	Estrogen receptor 1	ESR1**
				Androgen receptor	AR
				Prostaglandin G/H synthase 2	PTGS2*
				Trypsin-1	PRSS1
				Nuclear receptor coactivator 2	NCOA2
MOL008992	Wuweizisu C	46.27	0.84	Acetylcholinesterase	ACHE
				Gamma-aminobutyric acid receptor subunit alpha-1	GABRA1

成分代码	化合物名称	口服生物利用度（%）	药物相似性	靶点	靶点通用名
MOL004624	Longikaurin A	47.72	0.53	Muscarinic acetylcholine receptor M1	CHRM1
				Muscarinic acetylcholine receptor M2	CHRM2
				Trypsin-1	PRSS1
MOL005317	Deoxyharringtonine	39.27	0.81	Androgen receptor	AR
				Mineralocorticoid receptor	NR3C2
MOL008956	Angeloylgomisin O	31.97	0.85	Androgen receptor	AR
MOL008957	Schizandrer B	30.71	0.83	Prostaglandin G/H synthase 2	PTGS2*
MOL008968	Gomisin A	30.69	0.78	Acetylcholinesterase	ACHE
MOL008978	Gomisin R	34.84	0.86	Estrogen receptor 1	ESR1**
				Androgen receptor	AR
				Prostaglandin G/H synthase 2	PTGS2*
				Trypsin-1	PRSS1
				Nuclear receptor coactivator 2	NCOA2
MOL008992	Wuweizisu C	46.27	0.84	Acetylcholinesterase	ACHE
				Gamma-aminobutyric acid receptor subunit alpha-1	GABRA1
